The Heritage: The Perfect Stove For Large Spaces
If you're looking for a top-quality wood stove with blower, the Heritage Wood Stove is the perfect choice. It features a pedestal with ash drawer, blower, air deflector, ceramic glass, and ash lip, making it one of the most durable and efficient wood stoves on the market.
The Heritage Wood Stove also has an air damper that allows you to control the amount of airflow, so you can customize your heating experience. Whether you're looking for a primary heat source or a supplemental heater, the Heritage Wood Stove is the perfect option.
Heritage Wood Stove Features:
Up to 8 hours burn time
20" logs
2.4 ft³ firebox volume
Heavy duty 5/16" steel top
EPA certified
Proudly made in Canada
Limited lifetime warranty
Certified for mobile home and alcove installation
Weight : 350 lbs
Specifications
| Fuel type | Dry cordwood (16" recommended) |
|---|---|
| Recommended heating area(9) | 500 - 2,100 ft² |
| Overall firebox volume | 2.4 ft³ |
| EPA loading volume | 2.02 ft³ |
| Maximum burn time(9) | 8 h |
| Maximum heat output-dry cordwood(4) | 75,000 BTU/h (22 kW) |
| Minimum overall heat output rate(4) (5) | 14,800 BTU/h (4.34 kW) |
| Maximum overall heat output rate(4) (5) | 28,600 BTU/h (8.38 kW) |
| Average overall efficiency-dry cordwood (HHV)(5) (6) | 69% |
| Average overall efficiency-dry cordwood (LHV)(5) (7) | 74% |
| Optimum efficiency(1) (2) | 77% |
| Optimum heat transfer efficiency(8) | 75% |
| Average particulate emission rate(3) | 1.54 g/h |
| Average CO(10) | 89.4 g/h |
| Size | Large |
| Maximum log length | 20" |
| Shipping weight | 367 lb (166 kg) |
| Overall dimension (Width) | 26" |
| Overall dimension (Height) | 32 3/4" |
| Overall dimension (Depth) | 32" |
| Warranty | Limited lifetime |
| Alcove installation approved | Yes |
| Mobile home approved | Yes, with fresh air intake |
| Certified according to applicable standards | By an accredited laboratory (CAN/USA) |
| Premium quality blower included (CFM) | 100 CFM included |
| Combustion technology | Non-catalytic |
| Stainless-steel secondary-air system | Yes |
| Flue outlet diameter | 6" |
| Distance-center of the flue outlet to back unit | 11 1/2" |
| Distance-center of the flue outlet to side unit | 13" |
| Recommended chimney diameter | 6" |
| Type of chimney | CAN/ULC S629, UL 103 HT (2100 °F) |
| Minimum chimney height | 12' |
| Door type | Single, glass with cast iron frame |
| Door opening size (Width) | 17 1/2" |
| Door opening size (Height) | 9" |
| Glass type | Ceramic glass |
| Glass surface - W x H | 16" x 9 1/4" |
| Steel thickness-body | 3/16" |
| Steel thickness-top | 5/16" |
| Firebox size (Width) | 21" |
| Firebox size (Height) | 11 3/4" |
| Firebox size (Depth) | 16 3/4" |
| Log positioning | Loading over width |
| Firebox lined with refractory bricks | Yes |
| Baffle type | High quality vermiculite |
| High-efficiency certified appliance | Yes, EPA 2020 approved |
| Canadian Standard (emissions) | CSA B415.1-10 |
| USA Standard (emissions) | EPA |
| Canadian Standard (safety) | ULC S627 |
| USA Standard (safety) | UL 1482, UL 737 |
Clearance to Combustibles
| Single wall pipe | Double wall pipe | |
|---|---|---|
| Clearance - Side wall | 22" | 22" |
| Clearance - Corner | 12" | 12" |
| Clearance - Back wall | 11" | 6" |
| Clearance - Base of the unit to ceiling** | 84" | 84" |
Package Includes
Included: pedestal with ash drawer, blower, air deflector, ceramic glass, ash lip, air damper
Options: Thermodisc, firescreen, fresh air intake kit
Firebox lined with refractory bricks for better heat distribution
Optimum efficiency : 77 %
Average particulate emissions rate : 1.54 g/h
High-efficiency certified appliance : CSA B415.1-10
Steel thickness – top : 5/16"
Approved for a mobile home installation
Recommended heating area-ft² : 500 - 2,100
Blower included
Product Manual
